State-of-art GaN and GaAs MMICs and SiGe designs are available for product sales, prototyping and licensing. Our chips cover key functions for RF, microwave and mm-wave markets including aerospace, defence, and communications.

Filter by Min Frequency [GHz]

Filter by Max Frequency [GHz]

Filter by Gain [dB]

Filter by Noise Figure [dB]

Part Number	Description	Low Frequency	High Frequency	Gain	Noise Figure
VRFA0167-BD	1-2GHz LNA	1	2	22	0.9
VRFA0040-BD	5-12GHz LNA	5	12	25	1.7
VRFA0105-BD	5-18GHz GaN Robust LNA	5	18	12	4
VRFA0035-BD	6-18GHz LNA	6	18	19	2
VRFA0026-BD	7-11GHz LNA	7	11	24	1
VRFA0026-QFN	7-11GHz Packaged LNA	7	11	24	1.2
VRFA0164-BD	7-11GHz LNA	7	11	24	1.1
VRFA0164-BD	7-11GHz LNA	7	11	24	1.1
VRFA0028-BD	10-16GHz LNA	10	16	21	1.1
VRFA0145V2-BD	78-88GHz GaAs LNA	78	88	33	2.2
VRFA0146V2-BD	81-86GHz GaAs LNA	81	86	28	4.2

Page 1 of 1

Filter by Min Frequency [GHz]

Filter by Max Frequency [GHz]

Filter by Gain [dB]

Filter by Output Power [dBm]

Part Number	Min Frequency [GHz]	Max Frequency [GHz]	Gain [dB]	Output Power [dBm]
VRF250DV2-BD	93	95	18	17
VRF250DV3-BD	81	86	22	19
VRF250DV7-BD	71	76	17	17
VRF450DV2-BD	93	95	12	21.5
VRF450DV4-BD	81	86	14	18.5
VRF850DV2-BD	93	95	11	23.5
VRF850DV6-BD	81	86	14	23
VRFA0006-BD	2.4	5	26.5	25
VRFA0021-BD	1	45	12	15.5
VRFA0030-BD	2	20	11	18
VRFA0031-BD	2	20	14	18
VRFA0039V1-BD	25	27	22	35
VRFA0041V2-BD	7.5	8.75	23	42
VRFA0043V2-BD	8.5	11	21	39.5
VRFA0044-BD	7.25	8.5	23	39.5
VRFA0045V1-BD	25.5	27	25	25
VRFA0120-BD	5.2	5.6	46	47
VRFA0127-SG	25.5	27	27	40
VRFA0144-BD	16.5	17.6	22	44
VRFA0156-BD	9	10	30	41.5

Page 1 of 1

Filter by Min Frequency [GHz]

Filter by Max Frequency [GHz]

Filter by Loss [dB]

Filter by Isolation [dB]

Part Number	Description	Max Frequency [GHz]	Loss [dB]	Isolation [dB]
VRFS0003-BD	Wideband SP4T Switch	20	2.2	52
VRFS0002-BD	Wideband SPDT Switch	20	1.2	47
VRFS0008-BD	Wideband SPST Switch	20	0.6	48

Page 1 of 1

Filter by Min Frequency [GHz]

Filter by Max Frequency [GHz]

Filter by Conversion Gain

Part Number	Description	Min Frequency [GHz]	Max Frequency [GHz]	IF Frequency [GHz]	LO Frequency [GHz]	Conversion Gain
VRFC0136-SG	25.5-27GHz Double-Balanced Upconverter	25.5	27	7.8 - 8.6	17 / 17.4	27

Page 1 of 1

Filter by Min Frequency [GHz]

Filter by Max Frequency [GHz]

Filter by Gain [dB]

Filter by Noise Figure [dB]

Part Number	Description	Min Frequency [GHz]	Max Frequency [GHz]	Loss [dB]	Range [Degrees]
VRFC0010-180-BD	1-bit phase shifter	8	15	1.6	180
VRFC0010-90-BD	1-bit phase shifter	8	15	1.4	90
VRFC0010-45-BD	1-bit phase shifter	8	15	1.1	45
VRFC0011-5-BD	1-bit phase shifter	2	6	0.7	5.625
VRFC0011-22-BD	1-bit phase shifter	2	6	1.4	22.5
VRFC0003-BD	6-bit digital phase shifter	8	13	6	360
VRFC0008-BD	6-bit digital phase shifter	2	4	7.7	360

Page 1 of 1

Filter by Min Frequency [GHz]

Filter by Max Frequency [GHz]

Filter by Loss [dB]

Filter by Range [dB]

Part Number	Description	Min Frequency [GHz]	Max Frequency [GHz]	Loss [dB]	Range [dB]
VRFC0167-BD	5-Bit Digital Attenuator	0	10	2.4	15.5
VRFC0135-SG	7-Bit Digital Attenuator	7.8	8.6	6.5	31.5
VRFC0044-7-BD	Variable Voltage Attenuator	2	20	1	12
VRFC0009-16-BD	Wideband Switch Attenuator	0	20	16	0
VRFC0009-04-BD	Wideband Switch Attenuator	0	20	4	0
VRFC0009-02-BD	Wideband Switch Attenuator	0	20	2	0
VRFC0009-01-BD	Wideband Switch Attenuator	0	20	1	0
VRFC0006-BD	6-Bit Digital Attenuator	0	13	5	31.5
VRFC0007-BD	4-Bit Digital Attenuator	0	13	2.7	7.5

Page 1 of 1

Filter by Min Frequency [GHz]

Filter by Max Frequency [GHz]

Filter by Tx PSat [dBm]

Filter by Tx PAE [%]

Filter by Rx Gain [dB]

Filter by Rx Noise Figure [dB]

Part Number	Min Frequency [GHz]	Max Frequency [GHz]	Tx PSat [dBm]	Tx PAE [%]	Rx Gain [dB]	Rx Noise Figure [dB]
VRFC0127-BD	5.2	5.6	47	40	35	2.4

Page 1 of 1
